    Power Saving PET Water Bottle Moulding Machine 58kw-78KW Power Consumption

    Ask Lasest Price
    Brand Name : RiBo
    Model Number : RiBo-4CR10L
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 30 PCS/Year
    Delivery Time : 120 days
    • Product Details
    • Company Profile

    Power Saving PET Water Bottle Moulding Machine 58kw-78KW Power Consumption

    5 L / 10 L Oil bottle / Water Bottle Moulding Machine / PET stretching Two Step Machine

    Product Description

    Machine Features

    1. High quality compact machine Most popular pet bottle blowing machine.

    2. Produce PET Bottles ( such as: beverage, soybean,water,oil,vinegar bottles and so on)

    3. Easy to operate and maintain.

    4. High safety, high speed with high efficiency.

    5. Manual saving, one man is enough for operation the machine.

    6. Stable performing with easy maintaining.

    7. Japan Omron motion controlling system and man-machine interface computer.

    8. Adopted Japan Omron Servo motors.

    9. The simple slide-in way of mold mounting makes it possible for the operators to change molds easily within 30 minutes.

    10. Power saving design that can increase your profits.

    11. The cooling system for the preform neck is equipped to ensure the preform neck does not deform during heating and


    blowing.


    12. High pressure blowing air recovery system saves up to 30% of HPC air.


    13. Being highly intelligent, the machine is equipped with the units of preform temperature detection, leaking bottle detection and rejection as well as jammed air conveyor detection, ect, which ensures the machine work efficiently and stably.

    Technical Parameter


    ItemsUnitModel
    RiBo-4CR10L
    Molding Spec.Preform Pitchmm250
    Preform Heating Pitchmm63.5
    No.of Cav.cav.4

    Container Spec.
    Max.Container VolumeL10
    Neck Diameter Rangemm50
    Support ring diametermm57
    Max.Containr Diametermm220
    Max.Containr Heightmm460
    ※※ Theoretical Outputbph4000~3200
    Power Spec.Rateed PowerKW159
    Power ConsumptionKW58~78
    Compressor Spec.Blowing PressureMpa2.8~3.5
    Air Consumingm³/min12
    Main Machine Spec.Sizemm9836*3750*3520
    WeightKg10600
    Note: Due to continuous technical development specification would be improved without prior notice.
    Special designs correspond to customers needs.
